Maxtron Products

This Site is Under Construction

While we toil please contact our stocking distributor Markertek for the best prices and delivery!

Our products and solutions are designed with high quality, flexibility, molecularity, control and ease of use in mind. Applications are numerous and include broadcast multi-video & audio monitoring, master control rooms, outside broadcast (OB) trucks or mobile vehicles, mosaic & interactive channels, command & control, audiovisual presentations, security & surveillance, public information displays, and events and staging.

All products include a Universal Power Supply. Options include an internal Li-on Battery for the TG-5000, TG-5100, and TG-5120 and for the TG-5000 embedded audio, which is standard on all other products.

TG-5000 Dual-Format HD-SDI Pattern Generator
TG-5100 Multi-Format HD-SDI Pattern Generator with Voice ID
Multi-Format SD/HD-SDI Pattern Generator with Voice ID
Multi-Format HD/SD-SDI Pattern Generator with Voice & OSD
TG-5000 Dual-Format HD-SDI Pattern Generator
TG-5000
TG-5000 Dual-Format HD-SDI Pattern Generator
TG-5100 Multi-Format HD-SDI Pattern Generator with Voice ID
TG-5100
TG-5100 Multi-Format HD-SDI Pattern Generator with Voice ID
Multi-Format SD/HD-SDI Pattern Generator with Voice ID
TG-5120
Multi-Format SD/HD-SDI Pattern Generator with Voice ID
Multi-Format HD/SD-SDI Pattern Generator with Voice & OSD
TG-5130
Multi-Format HD/SD-SDI Pattern Generator with Voice & OSD

TG-5130 OSD Editor - Loader

The OSD Editor/Loader is used to program the text string into the TG-5130. It is a simple interface with few options. It will not check your spelling, correct errors, or fetch the existing OSD text. This is a Microsoft Windows 7/10 software program.

Download the OSD Software and install the program WITHOUT the TG-5130 connected to any USB port. If you are using a 64-bit machine the program will install in the following C:/Program Files (86)/Maxtron Products/TG_OSD directory. After the software is installed, DO NOT launch the program just yet, do this:

(1) The TG-5130 uses the FT245BT USB interface chip from FTDI and we must install their USB drivers before we plug-in the TG-5130 for the first time. Download the USB Drivers and install using Run as administrator option - remember to do this WITHOUT the TG-5130 connected to any USB port. Finally, you will be instructed to reboot your computer. Please reboot.

(2) Turn on the TG-5130 set it to either Pattern 0 or 1 (the OSD is not displayed on all test patterns) - it would be nice if the battery was charged! Connect the output of the TG-5130 to an SDI monitor so you can see what is going on.

(3) Now, plug-in the USB cable to the TG-5130 using a spare USB port on the computer. When the system is happy with the driver, you can

(4) Launch the program from the icon on the desktop.

(5) You will have no idea which COM port your computer chose to connect to the TG-5130 USB port, and neither do we. But we can help you find it - it usually is NOT COM1. Notice below that there is a Com menu item. Click on it and it will display all in use COM ports. Choose the highest numbered port to start.

(6) Notice that there is a little text box with the | in the middle. This is where you can enter the text you want displayed. ALL CAPS - no shift needed! You may NOT use these characters { } | ~ or any accented characters; 20 characters MAX and, yes, spaces and punctuation count. Once you have the text like you like - choose where in the raster you would like for the text to appear. Good. Now decide if you want White on Black or Black on White. Once you have all the options set, you can

(7) SAVE - writes to the internal ROM in the TG-5130, and do check that it was written correctly by cycling the TG-5130 power. If its all good - hit EXIT - and you are done.

(8) Remember, by default, the OSD does NOT appear on most of the TG-5130 patterns - just the ones with color bars. And, if you do not want any text on any pattern at anytime; go to Step 5 and select BLANK, Do Not click SAVE, and power cycle to make sure it is blank, and then EXIT.
